WU Haiqing, WANG Weichao. Design of Airborne Miniaturized Middle Wavelength Infrared Continuous Zoom Optical System[J]. Infrared Technology , 2021, 43(12): 1177-1182.
Citation: WU Haiqing, WANG Weichao. Design of Airborne Miniaturized Middle Wavelength Infrared Continuous Zoom Optical System[J]. Infrared Technology , 2021, 43(12): 1177-1182.

Design of Airborne Miniaturized Middle Wavelength Infrared Continuous Zoom Optical System

More Information
  • Received Date: December 31, 2020
  • Revised Date: November 24, 2021
  • To satisfy the requirements of an airborne electro-optical system for miniaturized and lightweight optical system of an infrared thermograph, a 22× continuous zoom optical system of 30–660 mm was realized by combining front-end afocal extender and back-end continuous zoom optical system. The total optical length of the system was 244 mm, and the total length/maximum focal length ratio was 0.37. The system had a small optical length and large zoom ratio, which makes the system suitable for large airborne electro-optical pod systems for long-distance detection. Upon removing the front afocal extender, the back-end system could achieve a 22× continuous zoom optical system of 15 to 330 mm. The total optical length of the system was 138 mm, and the total length/maximum focal length ratio was 0.42. The system can be used as a continuous zoom optical system in small-and medium-sized airborne electro-optical pod systems for close-range target detection. The design results exhibit that the system can capture images effectively in both states: at the characteristic frequency of 33 lp/mm corresponding to the detector, all the MTF values of the central field view were approximately 0.3, close to the diffraction limit, all the MTF values of the 0.7 field view were approximately 0.2, and all the MTF values of the edge field view were approximately 0.15, which satisfies the application requirements.
  • [1]
    王岭雪, 蔡毅. 红外成像光学系统进展与展望[J]. 红外技术, 2019, 41(1): 1-10. http://hwjs.nvir.cn/article/id/hwjs201901001

    WANG Lingxue, CAI Yi. Recent progress and perspectives of infrared optical systems[J]. Infrared Technology, 2019, 41(1): 1-10. http://hwjs.nvir.cn/article/id/hwjs201901001
    [2]
    吉书鹏. 机载光电载荷装备发展与关键技术[J]. 航空兵器, 2017(6): 3-12. https://www.cnki.com.cn/Article/CJFDTOTAL-HKBQ201706001.htm

    JI Shupeng. Equipment development of airborne electro-optic payload and its key technologies[J]. Aero Weaponry, 2017(6): 3-12. https://www.cnki.com.cn/Article/CJFDTOTAL-HKBQ201706001.htm
    [3]
    黄俊, 张正勇, 田省民. 机载对地光电探测设备现状及发展趋势研究[J]. 红外技术, 2018, 40(5): 412-416.

    HUANG Jun, ZHANG Zhengyong, TIAN Shengmin. Current status and development trend of airborne air to ground electro-optical detection equipment[J]. Infrared Technology, 2018, 40(5): 412-416.
    [4]
    王向军, 王敏. 适用于无人机小型吊舱的变焦控制系统设计[J]. 光电工程, 2013, 40(1): 139-144. https://www.cnki.com.cn/Article/CJFDTOTAL-GDGC201301025.htm

    WANG Xiangjuna, WANG Min. A zoom system design suitable for miniaturization of UAV pod[J]. Opto-Electronic Engineering, 2013, 40(1): 139-144. https://www.cnki.com.cn/Article/CJFDTOTAL-GDGC201301025.htm
    [5]
    薛慧, 李常伟. 红外中波连续变焦光学系统的设计[J]. 红外与毫米波学报, 2012, 31(5): 421-424. https://www.cnki.com.cn/Article/CJFDTOTAL-HWYH201205009.htm

    XUE Hui, LI Changwei. Optical design of infrared continuous-zoom lenses[J]. J. Infrared Millim. Wawes, 2012, 31(5): 421-424. https://www.cnki.com.cn/Article/CJFDTOTAL-HWYH201205009.htm
    [6]
    吴海清, 李同海, 赵新亮, 等. 大靶面中波红外连续变焦光学系统设计[J]. 红外, 2019, 40(1): 7-10. https://www.cnki.com.cn/Article/CJFDTOTAL-HWAI201901002.htm

    WU Haiqing, LI Tonghai, ZHAO Xinliang, et al. Design of large imaging plane middle wave infrared continuous zoom optical system[J]. Infrared, 2019, 40(1): 7-10. https://www.cnki.com.cn/Article/CJFDTOTAL-HWAI201901002.htm
    [7]
    王之江. 实用光学技术手册[M]. 北京: 机械工业出版社, 2007: 429-430.

    WANG Zhijiang. Practical Optical Technology Manual[M]. Beijing: China Machine Press, 2007: 429-430.
