4×128双色线列红外探测器成像电路设计

详细信息
  • 中图分类号: TN216

Imaging Circuit Design of 4×128 Two-color Linear Array Infrared Detector

  • 摘要: 介绍了针对4×128双色线列探测器而设计的成像电路系统,其硬件电路主要包括探测器适配电路、视频模拟信号调理电路、模数转换电路、图像预处理电路、数字图像输出接口电路等.探测器驱动时序、一维扫描成像时序、AD 采样时序和接口时序由 FPGA 来实现,采用 VHDL 语言完成时序设计.
